General Description:
Fluidized bed drying is the optimal method for controlled, gentle and even drying of wet solids. The intensive heat/mass exchange of the fluidized bed product makes this method particularly effective and time-saving. The technology is also suitable for post-drying of spray granulated or extruded products with very low residual moisture.
Fluidized bed drying can be used in the entire powder processing industry. In the pharmaceutical industry, this innovative method has replaced the time-consuming tray drying long ago. In addition, fluidized bed drying provides controlled and uniform drying conditions compared to the uneven drying in trays.
Properly used, fluidized bed drying provides an efficient solution for the gentle and even drying of your product.
Optional features:
Applications:
Specification :
| Lab-model | Pilot model | Production model | ||||||||
| Model | Unifluid Nano | Unifluid 3 | Unifluid 5 | Unifluid 10 | Unifluid 30 | Unifluid 60 | Unifluid 120 | Unifluid 200 | Unifluid 300 | Unifluid 500 |
| Capacity in Kgs at 0.6 gm/cc Bulk Density | 50gm - 1kg | 1-3 | 1-5 | 3-10 | 30 | 60 | 100 | 200 | 300 | 500 |
| Total Volume of Product Capacity in Litres |
500ml | 15 | 22 | 45 | 125 | 250 | 500 | 800 | 1100 | 1300 |
| Compressed Air required in CFM | NA | 3 | 3 | 5 | 7 | 7 | 10 | 10 | 15 | 20 |
| Steam Consumption Kg/ hr. | NA | NA | NA | NA | 35 | 80 | 150 | 220 | 350 | 450 |
| Heating Load in K.W. | 2 | 6 | 9 | 12 | NA | NA | NA | NA | NA | NA |
| Blower Motor H.P.* | 0.5 | 2 | 3 | 5 | 10 | 15 | 25 | 35 | 40 | 55 |
* *NA – Not Applicable
*CFM – Cubic Feet per minute
