V Blender

    Manufacturer and Supplier of V blender Machine

    • General Description
    • Optional Features
    • Specification

    General Description:

    ‘V’ Blenders uniformly displace materials for a complete blending of products via the intermeshed action of two inclined cylinders attached together in the form of a "V". This results in precise blending with short mix cycles. Tumble blending is most suited to products of uniform product size and density, and where requirements for fast, thorough cleaning are desirable in sanitary applications.

    For applications requiring dispersion of minor ingredients, and/or breaking up materials, which tend to form agglomerates, the blender can be equipped with a solids intensifier bar (beater or pin type), which is designed for ease of removal.

    For incorporation of liquids, the intensifier bar shaft is hollow, and equipped with a feed tube to dispense liquid between the beater bar discs in a finely atomized spray throughout the mix. Batch working capacities range from 1 cubic foot to 150 cubic feet.

    For products having poor flow properties, a shell design having a 70° angle is available upon request.

    Optional Features:

    • PLC Controlled
    • Speed Control via Variable Frequency Drive
    • Automated Drum loading system.

    Specification:

    MODEL Gross working capacity (lit) Working Capacity (lit) Overall dimensions (mm) Motor (HP) Weight (kg)
    L B H
    UNIBLENDER –VB LAB 1-30 0.7-21 - - - 0.5-1 250
    UNIBLENDER-VB100 100 70 2300 950 2100 3 800
    UNIBLENDER- VB300 300 320 2200 1050 2300 3 2000
    UNIBLENDER- VB500 500 350 2500 1500 3200 5 2600
    UNIBLENDER- VB1000 1000 700 2900 2700 4300 7.5 3000
    UNIBLENDER-VB2000 2000 1400 3200 1800 4400 10 4000
    UNIBLENDER- VB5000 5000 3500 4450 4520 4600 15 5500
    UNIBLENDER-VB10000 10000 7000 5900 3000 7000 25 7000

    Contact us for more information on Supply and Manufacturing of V Blender Machine or to discuss your requirements. Email us at sales@sbpanchal.com / hiren@sbpanchal.com
